    100W FDD COFDM IP Transmitter Digital Wireless Bi Directional 555MHz

    Ask Lasest Price
    Brand Name : Ding Shen
    Model Number : DS-FDD100W
    Price : negotiation
    Payment Terms : T/T
    Supply Ability : 3,000pcs per month
    Delivery Time : 3-7 works days
    • Product Details
    • Company Profile

    100W FDD COFDM IP Transmitter Digital Wireless Bi Directional 555MHz

    100W FDD-COFDM Ethernet Radio Full Duplex Long Range Bi-directional Wireless Communication


    Description:


    DS-FDD100W is a new COFDM digital transmitter receiver with Frequency-division duplexing (FDD) technology,designed with dual-mode rf transceiver architecture and system which operate at different carrier frequencies ideal for long range communication in network solution .The FDD technique uses different frequency bands for send and receive operations, the sending and receiving data signals don't interfere with each other that is suprior to Time Division Duplex (TDD) for symmetric traffic such as voice applications in broadband wireless networks.


    DS-FDD100W transceiver is implement of transparent IP ethernet interface that able balance and stable high-speed data rate with 30Mbit/s each for uplink and downlink.Highly integrated with Network/modulator& demodulator and full-band rf output all-in-one,which is ideal for Broadcasting,public security system,emergency system,Police,military and ect required for long distance wireless network links.


    2. Product features:
    1. Adopt non-standard COFDM modulation and demodulation technology
    2. Support non-line-of-sight (NLOS) and high-speed mobile transmission
    3. Low latency/end-to-end transmission of big data
    4. Transparent network/serial data transmission
    5. Support full-band/ultra-narrowband/multi-bandwidth adjustment (1M/2M/4M/8M


    Specifications:


    ModelDS-FDD100W
    Working voltageDC28V (AC110-240V)
    Working current14.5A/28V
    TX output frequency555MHz (can be customized 300-3300MHz),step in 1MHz
    RX output frequency595MHz (can be customized 300-3300MHz),step in 1MHz
    RF bandwidth1/2/4/8MHz
    RF power output50dBm (100W)
    Encryption/decryption modeAES128 bits(user-defined password)
    ModulationFDD-COFDM 2K
    Transfer rate2x30 Mbit/s uplink and downlink
    RF connectorN type *2
    EthernetStandard RJ45 port *2
    Serial portRS232/RS485 serial port
    Baud rate115200bps maximum
    Two way audioAviation plug
    LCD panel with keypadEasy to set the related parameters
    Dimension575*505*360mm
    Weight26
    Transmit distance30-50km NLOS /50-100km LOS

    100W FDD COFDM IP Transmitter Digital Wireless Bi Directional 555MHz 0


    100W FDD COFDM IP Transmitter Digital Wireless Bi Directional 555MHz 1


    100W FDD COFDM IP Transmitter Digital Wireless Bi Directional 555MHz 2

    100W FDD COFDM IP Transmitter Digital Wireless Bi Directional 555MHz 3


    Our Service:


    1. One-stop ODM/OEM solution;
    2. 24-hour technical support;
    3. Lifetime maintenance (Replacement parts will be charged after a year);
    4. Provide professional system design and construction;
    5. You will get good price and high quality here since we are an experienced manufacturer in wireless microwave transmission area since 1998, we are the source.


    Whatever your wireless surveillance application or budget, we can find the right solution for you.

    Contact us! We can customize any solution to fit your requirements.
