    HD COFDM Wireless Radio Receiver Video Data Transmission Equipment H.264

    Ask Lasest Price
    Brand Name : Ding Shen
    Model Number : DS-HDR50
    Price : negotiation
    Payment Terms : T/T
    Supply Ability : 3,000pcs per month
    Delivery Time : 3-7 works days
    • Product Details
    • Company Profile

    HD COFDM Wireless Radio Receiver Video Data Transmission Equipment H.264

    Product details

    HD COFDM Wireless Radio Receiver Video Data Transmission Equipment H.264


    Product Features:

    1. HD 1080P receiver;
    2. Supported multi-socket output;
    3. Transmit video and audio signal simultaneously.
    4. Can be with RS485/RS232 data control together.
    5. Rack design,easy to installed in Car


    Specifications:

    DC InputDC11V~DC16V
    Working Current≤1.1A DC12.5V
    Receiving sensitivity≤-102dBm @ /4MHz, ≤-95dBm @ /8MHz
    BERBER≤1×10-4
    Frequency input range300MHz~--470MHz
    Input interfaceN(type),Dual antenna diversity reception technology
    ModulationCOFDM
    RF bandwidth4/8MHz (adjustable)
    ConstellationQPSK,16QAM,64QAM (optional)
    EncryptionAES 128/265 bit / ALLTECH Basic scrambling
    FEC1/2,2/3,3/4,5/6, 7/8 (optional)
    Guard Interval1/32,1/16,1/8,1/4 (optional)
    Carrier2K
    Video formats and amplitudePAL/NTSC, 1Vp-p/75Ω
    Video compressionH.264/MPEG-2(autoadaptation)
    Decode code stream rate0.5-12Mbps
    Video output interfaceComposite video RCA,HD,ASI,HD-SDI(alternative)
    Interrupt recoveryBetter than 2S
    Video channel characteristicDifferential gain DG≤1.5%, Differential phase DP≤1°
    Audio outputLeft and right channel and stereo
    Dimension440*340*65mm(1U chassis)
    Weight:2kg

    FAQ:


    Q1: What can I buy from you?

    COFDM digital AV transmitter, IP mesh radio, analog video transmitter, radio data transceiver, and transmitter receiver OEM main board.

    Q2: Why should I choose you?

    Our core R&D team comes from the first-class university in China, major in communication engineering. We believe that wireless communication will keep on developing in professional markets in the future.

    Q3: Do you have a minimum order quantity?

    No MOQ limit, 1pc is acceptable.

    Q4: What kind of product service can I have?

    OEM & ODM service.

    Q5: What is the product warranty?

    We offer two-year-warranty and lifelong maintenance.

    Q6: What is the average lead time?

    5-7 working days for regular model, and 20-30 working days for customized model.

    Q7: What kinds of payment methods do you accept?

    We accept bank transfer, Western Union, PayPal, or cash payment.

    Q8: Can you supply the relevant documentation?

    Yes, we can provide most documentation including Certificates of Analysis / Conformance; Country of Origin, and other export documents where required.
